| CATAP. High-Voltage-Output DC/DC Converters in Portable Equipment | ||
| PROJECT INFORMATION |
 |
|
| Funding Entity: | Spanish Government / EU | |
| Partners: | SUINSA, Universidad de Oviedo | |
| Contract Period: | 07/11/2001 - 07/11/03 | |
| Total Budget: | 72,361€ | |
 |
||
| TECHNICAL SPECIFICATIONS | ||
| Equipment: | DC/DC Converter | |
| Output Voltage: | 50 kV | |
| Output Current: | 100 mA (max.) | |
| Output Power: | 5 kW (max.) | |
| Input Voltage: | 48 V (max.) | |
| Switching Frequency: | 100 kHz (max.) | |
| MAIN FEATURES | ||
|
The developed converter is intended for portable applications, such as cancer awareness campaigns (early breast cancer detection), VET applications, etc. The equipment will be operated in a bus; thus, the input power source is the bus batteries. It is very important to reduce the size and weight of the converter in order to develop a portable equipment. This implies increasing the switching frequency. In this converter, the switches are implemented using MOSFETs and the power stage is based on a resonant converter, in order to minimise losses. |
||
