| GPS. Grid Power Supply for Electron Beam Welding Machine | ||
| PROJECT INFORMATION |
 |
|
| Funding Entity: | Bodicote-TECHMETA | |
| Partners: | Bodicote-TECHMETA, Universidad de Oviedo | |
| Contract Period: | 09/01/2006 - 09/10/2006 | |
| Total Budget: | 9,000€ | |
 |
||
| TECHNICAL SPECIFICATIONS | ||
| Equipment: | DC/DC Converter | |
| Output Voltage: | 0 - 3.5 kV | |
| Output Current: | 72 mA (max.) | |
| Output Power: | 255 kW (max.) | |
| Input Voltage: | 96 V (max.) | |
| Switching Frequency: | 150 kHz (max.) | |
| MAIN FEATURES | ||
|
High-Voltage converters in welding machines applications operate with high voltages and high insulation. The output of the converter developed swings from 0 to 3.5kV with an insulation voltage of 80kV due to the main converter. These converters are designed to get low ripple in the output voltage. In this work, resonant converters were specifically dealt with. |
||
