$$ L=\left(\begin{array}{cccc} 0 & 0 & \cdots & 0\\ a_{21} & 0 & \cdots & 0\\ \vdots & \vdots & \ddots & \vdots\\ a_{n1} & a_{n2} & \cdots & 0 \end{array}\right)\;D=\left(\begin{array}{cccc} a_{11} & 0 & \cdots & 0\\ 0 & a_{22} & \cdots & 0\\ \vdots & \vdots & \ddots & \vdots\\ 0 & 0 & \cdots & a_{nn} \end{array}\right)\;U=\left(\begin{array}{cccc} 0 & a_{12} & \cdots & a_{1n}\\ 0 & 0 & \cdots & a_{2n}\\ \vdots & \vdots & \ddots & \vdots\\ 0 & 0 & \cdots & 0 \end{array}\right) $$

We have

$$ \begin{array}{l} A\mathbf{x}=\mathbf{b} \quad \Rightarrow \quad \left(L+D+U\right)\mathbf{x}=\mathbf{b} \quad \Rightarrow \quad \\[0.5cm] (L+D)\,\mathbf{x}=-U\mathbf{x}+\mathbf{b} \quad \Rightarrow \quad \mathbf{x}=-\left(L+D\right)^{-1}U\mathbf{x}+\left(L+D\right)^{-1}\mathbf{b} \end{array} $$

And if we call

$$ B_{G-S}=-\left(L+D\right)^{-1}U \quad \mathbf{c}_{G-S}=\left(L+D\right)^{-1}\mathbf{b} $$

we can write

$$ \mathbf{x}=B_{G-S}\mathbf{x}+\mathbf{c}_{G-S} $$

And we can perform iterations using

$$ \mathbf{x}^{(k+1)}=B_{G-S}\mathbf{x}^{(k)}+\mathbf{c}_{G-S} $$

starting with the initial guess $\mathbf{x}^{(0)}$

$$ \mathbf{x}^{(1)}=B_{G-S}\mathbf{x}^{(0)}+\mathbf{c}_{G-S}, \quad \mathbf{x}^{(2)}=B_{G-S}\mathbf{x}^{(1)}+\mathbf{c}_{G-S}, \quad \mathbf{x}^{(3)}=B_{G-S}\mathbf{x}^{(2)}+\mathbf{c}_{G-S}, \quad \ldots $$

Exercise¶

Is $A$ diagonally dominant?¶

A matrix $A$ of $n$ rows and $n$ columns is diagonally dominant if

$$ \sum_{j=1\\i\ne j}^n|a_{ij}|\lt |a_{ii}|\quad i=1,\ldots,n $$

For the matrix $A$

$$A=\left(\begin{array}{crr} \fbox{$4$} & 1 & 0\\ 1 & \fbox{$4$} & 3\\ 0 & 3 & \fbox{$4$} \end{array}\right)\begin{array}{r} \left|1\right|+\left|0\right|\lt\left|4\right|\\ \left|1\right|+\left|3\right|\nless\left|4\right|\\ \left|0\right|+\left|3\right|\lt\left|4\right| \\ \end{array}$$

Calculate the infinity norm, the $1-$norm and the eigenvalues of $B_{G-S}$¶

The iteration matrix is $B_{G-S}=-(L+D)^{-1}U$. If

$$ A=\left(\begin{array}{ccc} 4 & 1 & 0\\ 1 & 4 & 3\\ 0 & 3 & 4 \end{array}\right) $$

then

$$ L=\left(\begin{array}{ccc} 0 & 0 & 0\\ 1 & 0 & 0\\ 0 & 3 & 0 \end{array}\right) \quad D=\left(\begin{array}{ccc} 4 & 0 & 0\\ 0 & 4 & 0\\ 0 & 0 & 4 \end{array}\right) \quad U=\left(\begin{array}{ccc} 0 & 1 & 0\\ 0 & 0 & 3\\ 0 & 0 & 0 \end{array}\right) $$

$$ L+D=\left(\begin{array}{ccc} 4 & 0 & 0\\ 1 & 4 & 0\\ 0 & 3 & 4 \end{array}\right) $$

Let us compute the inverse by Gauss-Jordan

We write the matrix $\left[(L+D)|I\right]$. As the pivot is $\mathbf{{\color{red}4}}$ we divide the row by $4$ to get a $1$ in the pivot position

$$ \begin{array}{c} r_{1}\\ r_{2}\\ r_{3} \end{array}\left(\begin{array}{rrr|rrr} {\mathbf{{\color{red}4}}} & 0 &0 & 1 & 0 & 0\\ \mathbf{{\color{blue}1}} & 4 & 0 & 0 & 1 & 0\\ \mathbf{{\color{ForestGreen}0}} & 3 & 4 & 0 & 0 & 1 \end{array}\right) \begin{array}{rrl} r_{1} & = & r_{1}/(\mathbf{\color{red}{4}})\\ & &\\ & & \end{array} $$

$$ \begin{array}{c} r_{1}\\ r_{2}\\ r_{3} \end{array}\left(\begin{array}{rrr|rrr} {\mathbf{{\color{red}1}}} & 0 & 0 & 1/4 & 0 & 0\\ \mathbf{{\color{blue}1}} & 4 & 0 & 0 & 1 & 0\\ \mathbf{{\color{ForestGreen}0}} & 3 & 4 & 0 & 0 & 1 \end{array}\right) \begin{array}{rrl} r_{1}\\ r_{2} & = & r_{2}-\mathbf{{\color{blue}1}}r_{1}\\ r_3 & = & r_{3}-\mathbf{{\color{ForestGreen}0}}r_{1} \end{array} $$

We make zeros below the pivot

$$ \begin{array}{c} r_{1}\\ r_{2}\\ r_{3} \end{array}\left(\begin{array}{rrr|rrr} 1 & \mathbf{{\color{blue}0}} & 0 & 1/4 & 0 & 0\\ 0 & {\mathbf{{\color{red}4}}} & 0 & -1/4 & 1 & 0\\ 0 & \mathbf{{\color{ForestGreen}3}} & 4 & 0 & 0 & 1 \end{array}\right) \begin{array}{rrl} & &\\ r_{2} & = & r_{2}/(\mathbf{\color{red}{4}})\\ & & \end{array} $$

As the pivot is $\mathbf{{\color{red}4}}$ we divide all the row by 4 to convert it into a 1.

$$ \begin{array}{c} r_{1}\\ r_{2}\\ r_{3} \end{array}\left(\begin{array}{rrr|rrr} 1 & \mathbf{{\color{blue}0}} & 0 & 1/4 & 0 & 0\\ 0 & {\mathbf{{\color{red}1}}} & 0 & -1/16 & 1/4 & 0\\ 0 & \mathbf{{\color{ForestGreen}3}} & 4 & 0 & 0 & 1 \end{array}\right) \begin{array}{rrl} r_{1} & = & r_{1}-\mathbf{{\color{blue}0}}\,r_{2}\\ r_{2}\\ r_3 & = & r_{3}-\mathbf{{\color{ForestGreen}3}}\,r_{2} \end{array} $$

We make zeros above and below the pivot (although above there is already a zero and nothing needs to be done)

$$ \begin{array}{c} r_{1}\\ r_{2}\\ r_{3} \end{array}\left(\begin{array}{rrr|rrr} 1 & 0 & \mathbf{{\color{blue}0}} & 1/4 & 0 & 0\\ 0 & 1 & \mathbf{{\color{ForestGreen}0}} & -1/16 & 1/4 & 0\\ 0 & 0 & {\mathbf{{\color{red}4}}} & 3/16 & -3/4 & 1 \end{array}\right) \begin{array}{rrl} & &\\ & &\\ r_{3} & = & r_{3}/(\mathbf{\color{red}{4}}) \end{array} $$

We divide the row of the pivot by the pivot, and since above it there are only zeros, we have finished.

$$ \begin{array}{c} r_{1}\\ r_{2}\\ r_{3} \end{array}\left(\begin{array}{rrr|rrr} 1 & 0 & 0 & 1/4 & 0 & 0\\ 0 & 1 & 0 & -1/16 & 1/4 & 0\\ 0 & 0 & 1 & 3/64 & -3/16 & 1/4 \end{array}\right) $$

Since we already have the matrix $I$ on the left, the matrix on the right will be $(L+D)^{-1}$.

$$ (L+D)^{-1} = \left(\begin{array}{rrr} 1/4 & 0 & 0\\ -1/16 & 1/4 & 0\\ 3/64 & -3/16 & 1/4 \end{array}\right) $$

We multiply it by $U$

$$ B_{G-S} = -(L+D)^{-1}\,U= -\left(\begin{array}{rrr} 1/4 & 0 & 0\\ -1/16 & 1/4 & 0\\ 3/64 & -3/16 & 1/4 \end{array}\right) \left(\begin{array}{ccc} 0 & 1 & 0\\ 0 & 0 & 3\\ 0 & 0 & 0 \end{array}\right)= \left(\begin{array}{rrr} 0 & -1/4 & 0\\ 0 & 1/16 & -3/4\\ 0 & -3/64 & 9/16 \end{array}\right) $$

Infinity norm. If $A$ is an $m\times n$ matrix the infinity norm is given by

$$ \|A\|_{\infty} = \max_{1\leq i \leq m}\sum_{j=1}^n|a_{ij}| $$

We move to floating point to better compare quantities and study the infinity norm.

$$ B_{G-S}=\left(\begin{array}{rrr} 0 & -0.25 & 0\\ 0 & 0.06 & -0.75\\ 0 & -0.05 & 0.56 \end{array}\right)\begin{array}{l} 0+0.25+0=0.25\\ 0+0.06+0.75=0.81\\ 0+0.05+0.56=0.61 \end{array} $$

Then

$$ \left|\left|B_{G-S}\right|\right|_{\infty}=\textrm{Max} \left(0.25,0.81,0.61\right)=0.81 $$

1-norm If $A$ is an $m\times n$ matrix its $1-$norm is

$$ \|A\|_1 = \max_{1\leq j \leq n}\sum_{i=1}^m|a_{ij}| $$

$$ B_{G-S}^T=\left(\begin{array}{ccc} 0 & 0 & 0\\ -0.25 & 0.06 & -0.05\\ 0 & -0.75 & 0.56 \end{array}\right)\begin{array}{l} 0+0+0=0\\ 0.25+0.06+0.05=0.36\\ 0+0.75+0.56=1.31 \end{array} $$

Then

$$ \left|\left|B_{G-S}\right|\right|_{1}=\textrm{Max} \left(0,0.36,1.31\right)=1.31 $$

Eigenvalues We calculate the eigenvalues of $B_{G-S}$

$$ \left(\begin{array}{rrr} 0 & -1/4 & 0\\ 0 & 1/16 & -3/4\\ 0 & -3/64 & 9/16 \end{array}\right) $$

Computing the roots of $|B_{G-S}-\lambda I|=0$

$$ \left|\begin{array}{ccc} 0-\lambda & -1/4 & 0\\ 0 & (1/16)-\lambda & -3/4\\ 0 & -3/64 & (9/16)-\lambda \end{array}\right|= $$

. $$ =-\lambda\left|\begin{array}{cc} (1/16)-\lambda & -3/4\\ -3/64 & (9/16)-\lambda \end{array}\right|= $$ . $$ =-\lambda \left[ \left(\frac{1}{16}-\lambda\right)\left(\frac{9}{16}-\lambda\right)-\left(-\frac{3}{4}\right)\left(-\frac{3}{64}\right)\right]= $$ . $$ =-\lambda\left[\left(\frac{1}{16}-\lambda\right)\left(\frac{9}{16}-\lambda\right)-\frac{9}{4\times 64} \right]= $$ . $$ =-\lambda\left[\frac{1}{16}\times\frac{9}{16}-\frac{1}{16}\lambda-\frac{9}{16}\lambda+\lambda^2-\frac{9}{2^2\times 2^6} \right]= $$ .

$$ =-\lambda\left[\frac{9}{2^8}-\frac{10}{16}\lambda+\lambda^2-\frac{9}{2^2\times 2^6} \right]=-\lambda^2\left(-\frac{10}{16}+\lambda\right)=-\lambda^2\left(\lambda-\frac{5}{8}\right) $$

And the eigenvalues are

$$ \lambda_{1,2}=0,\quad\lambda_{3}=\frac{5}{8}=0.625 $$

From each of the previous results, what can we conclude about the convergence of the Gauss-Seidel method?¶

It is a sufficient condition for the convergence of the Gauss-Seidel method that the coefficients matrix $A$ is diagonally dominant by rows:

Since $A$ is not diagonally dominant, we cannot conclude anything.

It is a sufficient condition for the convergence of the Gauss-Seidel method that some norm of the iteration matrix $B_{G-S}$ is less than $1.$

As $\left|\left|B_{G-S}\right|\right|_{\infty}\lt 1$ we can conclude that the Gauss-Seidel method converge for this system. (And it would not be necessary to continue and obtain the other norm or the eigenvalues, although we have done it to verify that the results are consistent).
From $\left|\left|B_{G-S}\right|\right|_{1}\gt 1$ we could not conclude anything.

It is a necessary and sufficient condition for the convergence of the Gauss-Seidel method that all the eigenvalues of the iteration matrix $B_{G-S}$ are less than $1$ in absolute value.

As all the eigenvalues of $B_{G-S}$ are less than one in absolute value, we can conclude that the Gauss-Seidel method will converge for any initial guess.

Perform 3 iterations with Gauss-Seidel starting with $\mathbf{x}^{(0)}=(0,0,0)^T$¶

The system is $A\mathbf{x}=\mathbf{b}$ with

$$ A=\left(\begin{array}{ccc} 4 & 1 & 0\\ 1 & 4 & 3\\ 0 & 3 & 4 \end{array}\right)\quad\mathbf{b}=\left(\begin{array}{c} 3\\ 3\\ 5 \end{array}\right) $$

If we write the equations

$$ \begin{array}{rrrrrr} 4x & +&y & & & = & 3\\ x & +&4y & +&3z & = & 3\\ & &3y & +&4z & = & 5 \end{array} $$

In the first equation we solve for the first unknown, $x$, in the second, the second unknown, $y$, and finally, $z.$

$$ \begin{array}{ccl} x & = & \dfrac{3-y}{4}\\ y & = & \dfrac{3-x-3z}{4}\\ z & = & \dfrac{5-3y}{4} \end{array} $$

We perform the iterations starting with the values of the previous iteration, but as we get new values, we use them

$$ \begin{array}{ccl} x^{\color{red}{(1)}} & = & \dfrac{3-y^{(0)}}{4}\\ y^{\color{red}{(1)}} & = & \dfrac{3-x^{\color{red}{(1)}}-3z^{(0)}}{4}\\ z^{\color{red}{(1)}} & = & \dfrac{5-3y^{\color{red}{(1)}}}{4} \end{array} $$

Iteration 1

We perform an iteration, taking as initial value, the null vector

$$ \begin{array}{ccl} x^{\color{red}{(1)}} & = & (3-y^{(0)})/4=(3-0)/4=3/4= 0.75\\ y^{\color{red}{(1)}} & = & (3-x^{\color{red}{(1)}}-3z^{(0)})/4=(3-0.75-0)/4=0.56\\ z^{\color{red}{(1)}} & = & (5-3y^{\color{red}{(1)}})/4= (5-3(0.56))/4= 0.83 \end{array} $$

Iteration 2

$$ \begin{array}{ccl} x^{\color{red}{(2)}} & = & (3-y^{(1)})/4=(3-0.56)/4=0.61\\ y^{\color{red}{(2)}} & = & (3-x^{\color{red}{(2)}}-3z^{(1)})/4=(3-0.61-3(0.83))/4=-0.02\\ z^{\color{red}{(2)}} & = & (5-3y^{\color{red}{(2)}})/4= (5-3(-0.02))/4= 1.27 \end{array} $$

Iteration 3

$$ \begin{array}{ccl} x^{\color{red}{(3)}} & = & (3-y^{(2)})/4=(3-(-0.02))/4=0.76\\ y^{\color{red}{(3)}} & = & (3-x^{\color{red}{(3)}}-3z^{(2)})/4=(3-0.76-3(1.27))/4=-0.39\\ z^{\color{red}{(3)}} & = & (5-3y^{\color{red}{(3)}})/4= (5-3(-0.39))/4= 1.54 \end{array} $$

The exact solution is

$$x = 1\quad y = -1 \quad z = 2$$

Algorithm¶

Given an initial guess $\mathbf{x}^{(0)}$
For $k=1,2,\ldots,$MaxIter
- For $i=1,2,\ldots,n$, compute $$x_{i}^{\color{red}{(k)}}=\dfrac{1}{a_{ii}}\left(b_{i}-\sum_{j=1}^{i-1}a_{ij}x_{j}^{\color{red}{(k)}}-\sum_{j=i+1}^{n}a_{ij}x_{j}^{(k-1)}\right)$$
- If the stopping condition is met, take $\mathbf{x}^{(k)}$ as approximation of the solution.
