Equipment

In the laboratory located in the Viesques Campus, in Gijón, Spain, the Research Group has a prototype of a monophile N-S tracker with 8 panels, 4 in 1V configuration and 4 in 2H configuration. We also have a prototype of a small-scale Linear Fresnel Reflector, 75 photovoltaic modules, some installed on the facade of the building, and others on the roof. We have a weather station and two pyranometers, one for diffuse irradiance and the other for global and reflected irradiance. We also have a network analyser, I-V curve analyser and other complementary equipment.



In addition, we have licences for various simulation software programmes, such as TRNSYS, PVSYST, SolidWorks and Symbolic Calculation programmes such as Matlab or Mathematica.



Tracker monofila con 8 paneles
Sistema de ensayo de un Módulo Híbrido Fotovoltaico-Térmico
Reflector Lineal Fresnel de pequeña escala	Módulos Fotovoltaicos fachada
Módulos Fotovoltaicos terraza	Analizador de Redes
Analizador de Curvas I-V	Piranometro Irradiancia Difusa
Piranometro Irradiancia Global y Reflejada	Sistema Monitorización Irradiancia
Unidad Adquisicion Datos	Vatimetro Digital
